Термическое зондирование атмосферы Марса при помощи фурье-спектрометра ACS TIRVIM на борту КА ExoMars TGO: метод решения обратной задачи
П. В. Власов a, *, Н. И. Игнатьев a, О. И. Кораблев a, А. А. Федорова a, А. В. Григорьев b, Д. В. Пацаев a, И. А. Маслов a, А. В. Шакун a, С. Герле c, Д. Грасси d, Л. В. Засова a
a Институт космических исследований РАН (ИКИ РАН)
Москва, Россия
b Австралийский национальный университет
Канберра, Австралия
c LMD/IPSL
Париж, Франция
d INAF-IAPS
Рим, Италия
* E-mail: pavel.vlasov@phystech.edu
Поступила в редакцию 31.05.2023
После доработки 10.07.2023
Принята к публикации 15.07.2023
- EDN: DHQOZM
- DOI: 10.31857/S0320930X23060087
Полные тексты статей выпуска доступны в ознакомительном режиме только авторизованным пользователям.
Аннотация
В данной работе представлен метод решения обратной задачи термического зондирования по калиброванным данным эксперимента ACS TIRVIM на борту КА ExoMars Trace Gas Orbiter. Фурье-спектрометр TIRVIM диапазона 1.7–17 мкм в составе приборного комплекса ACS на борту ExoMars TGO работает в надирном режиме и в режиме солнечных затмений на орбите вокруг Марса. Основной научной задачей TIRVIM в надирном режиме наблюдений является постоянный мониторинг тепловой структуры марсианской атмосферы и общего содержания аэрозолей и водяного пара по измерениям в диапазоне 5–16.7 мкм (600–2000 см–1). Для обработки надирных измерений TIRVIM был разработан алгоритм, позволяющий восстановить вертикальный температурный профиль от поверхности до 60 км, температуру поверхности и общее содержание пыли и водяного льда в атмосфере по полученному TIRVIM спектру в диапазоне 600–1250 см–1, а также общее содержание водяного пара по измерениям в диапазоне 1250–1830 см–1. Метод обработки широко использует наработки предыдущих похожих экспериментов с учетом особенностей спектров TIRVIM. Разработанным методом было обработано 2.28 × 106 спектров, полученных TIRVIM в надир регулярными измерениями, для которых была восстановлена тепловая структура до 60 км высоты и содержание аэрозолей в атмосфере, а также дополнительно получено и обработано 2.3 × 105 специально усредненных спектров TIRVIM, для которых проведено восстановление общего содержания водяного пара в атмосфере Марса.
